Item No.:
HET-280P60AMax Power:
280WWeight:
18.5kgDimension:
1640*992*35mmWarranty:
25yearsCertification:
CE/FCC/ROHS/ISOPayment :
T/T, L/C, Paypal, Western UnionProducts Name:
280 watts polycrystalline solar panels
Applications:
These robust and reliable solar panels are waterproof and perfect for outdoor conditions. They are most effective, versatile and cost saving in many commercial and leisure applications for charging 12V batteries. They are particularly suited for on the move applications such as:Boating/Caravan/Motor Homes/on grid solar power system.
Electrical Characteristics(STC):
|
Mechanical Characteristics |
||||
|
Front Glass |
3.2mm high transmission tempered glass |
|||
|
Encapsulation |
EVA |
|||
|
Cells |
60pcs 156×156mm Monocrystalline solar cells |
|||
|
Backsheet |
Composite film |
|||
|
Frame |
Anodized aluminum profile |
|||
|
Junction Box |
Rated current:20A,IP68,TUV |
|||
|
Cables |
length 900mm;customized length |
|||
|
Connectors |
Compatible with MC4 |
|||
|
Module Type |
HET-280P60A |
HET-285P60A |
HET-290P60A |
HET-295P60A |
|
Maximum Power (Pmax) |
280W |
285W |
290W |
295W |
|
Open-circuit Voltage (Voc) |
38.4V |
38.5V |
38.6V |
38.7V |
|
Short-circuit Current (Isc) |
9.29A |
9.39A |
9.44A |
9.52A |
|
Maximum Power Voltage (Vmp) |
31.6V |
31.8V |
32.0V |
32.2V |
|
Maximum Power Current (Imp) |
8.86A |
8.96A |
9.06A |
9.16A |
|
Module Efficiency(%) |
17.1% |
17.4% |
17.7% |
18.1% |
|
Power Tolerance |
0~+5W |
|||
|
Standard Test Environment |
Irradiance 1000W/m2, Cell Temperature 25℃，Spectrum AM 1.5 |
|||
Features and Benefits:
• High efficiency crystalline solar cells for “all weather” charging
• Water resistant, robust construction for outdoor use and long service life
• Modules are designed in accordance with IEC61215:1993
• Waterproof junction box and terminals for quick and easy connection
• Battery Overcharge Protection
• Proven material and tempered front glass
More Products information pls contact with us mail :coco20.xu@gmail.com.
Previous :
285w poly solar panel with 60 cellsNext :
275 watts 60 cell pv panelIf you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Hetech Solar Polycrystalline solar panels with PID resistance Technology (Potential-Induced Degradation) for safety against substantial power loss due to stray currents triggered by certain climate conditions.
Top quality solar panels from 260 to 400 watts. Competitively priced with specials available from time to time. Solar panels are generally in stock, ready to be shipped to you within 24 hours.
Polycrystalline solar panels generally have lower efficiencies than monocrystalline options, but their advantage is a lower price point. In addition, polycrystalline solar panels tend to have a blue hue instead of the black hue of monocrystalline panels. Power range from POLY 260W to POLY 400W.
The 60-cell module like every Hetech solar module has high-quality solar cells with highest efficiency at the best possible low light behaviour to ensure the best energy output.
Polycrystalline solar panels generally have lower efficiencies than monocrystalline options, but their advantage is a lower price point. In addition, polycrystalline solar panels tend to have a blue hue instead of the black hue of monocrystalline panels. Power range from POLY 260W to POLY 400W.
Hetech Polycrystalline Solar Panel is the key component to a system when going solar Off Grid system . These panels are relatively compact and are a breeze to set up. Whether for your home or a manufacture popurse, this panel can be a great start to your off-grid system! This panel has several uses including marine, and other off-grid applications.
Polycrystalline solar panels generally have lower efficiencies than monocrystalline options, but their advantage is a lower price point. In addition, polycrystalline solar panels tend to have a blue hue instead of the black hue of monocrystalline panels. Power range from POLY 260W to POLY 400W.
PV modules, are rational designed, excellent in workmanship, and have a stable performance 9BB solar panels,power range covers 390W-405W, are widely used in photovoltaic power stations.
