Assembled with multi-busbar (9BB) PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk.
Item No.:
HET-345M60AHMax Power:
345WWeight:
20.5kgDimension:
1776*1052*35mmWarranty:
25yearsCertification:
TUV/CE/CEC/FCC/CQC/ISO/ROHSPayment :
T/T, L/C, Paypal, Western Union
Products Name:
120 half cells solar panel high power 9BB 340W 350W 360W
Electrical Characteristics(STC):
| Mechanical Characteristics | ||||
|
Front Glass |
3.2mm high transmission tempered glass |
|||
|
Encapsulation |
EVA |
|||
|
Cells |
120pcs 166×83mm Monocrystalline solar cells |
|||
|
Backsheet |
Composite film |
|||
|
Frame |
Anodized aluminum profile |
|||
|
Junction Box |
Rated current:15A,IP68,TUV |
|||
|
Cables |
length 300mm;customized length |
|||
|
Connectors |
Compatible with MC4 |
|||
|
Module Type |
HET-340M60HA |
HET-345M60HA |
HET-350M60HA |
HET-355M60HA |
|
Maximum Power (Pmax) |
340W |
345W |
350W |
355W |
|
Open-circuit Voltage (Voc) |
39.55V |
39.76V |
40.1V |
40.3V |
|
Short-circuit Current (Isc) |
10.46A |
10.54A |
11.15A |
11.25A |
|
Maximum Power Voltage (Vmp) |
33.2V |
33.4V |
33.6V |
33.8V |
|
Maximum Power Current (Imp) |
9.79A |
9.86A |
10.42A |
10.51A |
|
Module Efficiency(%) |
18.2% |
18.5% |
18.7% |
19.0% |
|
Power Tolerance |
0~+5W |
|||
|
Standard Test Environment |
Irradiance 1000W/m2, Cell Temperature 25℃，Spectrum AM 1.5 |
|||
Packing Details:
|
Container |
20GP |
40GP |
40HC |
|
Pcs/pallet |
30 |
30 |
30 |
|
Pallet/container |
6 |
12 |
26 |
|
Pcs/container |
180 |
360 |
780 |
To Parterners:
Our Advantages:
1.OEM acceptable in MOQ order.
2.Quality Promission, We are not the cheapest but the only one who can make sure the Europe level quality by refunding.
3.Quick delivery based our own factory, some Germany customer solar panels in stock.1000PCS less in 15days.
4.Flexible payment terms.
More Products information pls contact with us mail :coco20.xu@gmail.com.
Previous :
370W 9BB Solar Panel With 120 Half Cut Solar Cell For Solar Power SystemNext :
High Power 340-375W 9BB Half-Cell Solar PanelIf you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Monocrystalline 9BB half cell solar panel 420-450W 144cells ,high power, anti-hotspot, on grid system, off grid system, residencial solar system
Assembled with high-efficiency PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.
Assembled with high-efficiency PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.
Assembled with high-efficiency PERC cells, Applications: Grid-tie, hybrid systems, off-grid, caravans, motorhomes.
Assembled with high-efficiency PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.
Hetech 9BB solar model is also a great option to consider to power your appliances. Designed with 9BB monocrystalline cells ,power ranges from 340W to 440W that is good enough to fit high power need.
9bb (busbar) Busbars distribute electricity with greater ease and flexibility. It is a thin strip of copper or aluminium between cells that conducts electricity which is called a busbar. It separates solar cells and conducts the direct current the cells collected from solar photon to the solar inverter, which converts the direct current into the useable current.
